Key Features
- MPN: EN42270
- Model: NYX Air II
- Motherboard Support: Micro ATX & Mini ITX
- Material: Steel
- PCI Slot: 4 Standard Slots
- Connectors: USB 3.0 x1, USB 2.0 x2, HD Audio
Specification
| Case Type | ||
| Type | Mid-Tower | |
| Tempered Glass Panel | Left Tempered Glass | |
| Motherboard Support | M-ATX, Mini ITX | |
| External Features | ||
| Color(s) | Black | |
| Material | Steel | |
| Dimensions | 386x200x411mm (LxWxH) | |
| Front Ports | USB 3.0 x 1, USB 2.0 x 2, HD Audio | |
| Expansion Slots | 4 Standard Slots | |
| Radiator Support | Front: 240mm Rear: 120mm |
|
| Fan Support | Top: 120mm x2 Front: 120mm x3 (Internal) PSU Shroud: 120mm x2 Rear: 120mm x1 |
|
| Drive Bays | Bottom Panel: 3.5″ x1 PSU Shroud: 3.5″ or 2.5″ x1 MB SSD Bay: 2.5″ x2 |
|
| I/O Port | USB 3.0 x 1, USB-C x 1, HD Audio | |
| Additional Feature | ||
| PSU | Not Include | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 160mm | |
| Maximum Graphics Card Length | 325mm (with Front Fans) 350mm (without Front Fans) |
|
| Maximum PSU Length | 165mm | |
| Warranty | ||
| Warranty | No Warranty | |
