Key Features
- MPN: EN41822
- Model: Endorphin Air V2
- Motherboard Support: E-ATX, ATX, M-ATX, Mini ITX
- Front & Left Panel Tempered Glass Design
- PCI Slot: 7 Standard Slots
- Connectors: 2x USB3.0, 1x USB-C, HD Audio
Specification
| Case Type | ||
| Type | Mid Tower | |
| Tempered Glass Panel | Two-Sided Tempered Glass | |
| Motherboard Support | E-ATX, ATX, M-ATX, Mini ITX | |
| External Features | ||
| Color(s) | Black | |
| Material | Steel | |
| Dimensions | 435x218x456mm(LxWxH) | |
| Expansion Slots | 7 Standard Slots | |
| Radiator Support | Top: 360mm (Memory Height ≤45mm) MB Panel: 240mm (EATX MB Width ≤28cm) Rear: 120mm |
|
| Fan Support | Top: 120mm x3 or 140mm x2 MB: 120mm x3 (EATX MB Width ≤28cm) HDD Cage: 120mm x1 PSU Shroud: 120mm x2 Rear: 120mm x1 |
|
| Pre- Installed Fans | No | |
| Drive Bays | HDD Cage(Bottom): 3.5″ x1 HDD Cage(Top): 3.5″ & 2.5″ Combo x1 SSD Bracket: 2.5″ x2 |
|
| I/O Port | USB3.0 x2 Type C x1 HD Audio |
|
| Additional Feature | ||
| PSU | Standard PS2 ATX PSU | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 170mm | |
| Maximum Graphics Card Length | 285mm (Fan on MB Panel) 420mm (No Fan on MB Panel) |
|
| Maximum PSU Length | 200mm | |
| Warranty | ||
| Warranty | No Warranty | |
