Key Features
- MPN: EN40078
- Model: Aqua M
- Motherboard Support: Micro-ATX, MINI-ITX
- Material: Tempered Glass and Steel
- PCI Slot: 4 Standard Slot
- Connectors: USB3.0 x 1 – USB2.0 x2 – Audio in/out x 1 (HD Audio)
Specification
| Case Type | ||
| Tempered Glass Panel | Yes | |
| Motherboard Support | Micro-ATX, MINI-ITX | |
| External Features | ||
| Color(s) | Black | |
| Material | Tempered Glass and Steel | |
| Dimensions | 348 x 280 x 378mm | |
| Front Ports | 1 x USB3.0, 2 x USB2.0, HD Audio | |
| Expansion Slots | 4 Standard Slot | |
| Radiator Support | Top: 240mm MB Panel: 240mm (Fan & Radiator Separate Installation) |
|
| Fan Support | Top: 120mm x2 Bottom: 120mm x2 MB Panel: 120mm x2 Rear: 120mm x1 |
|
| Drive Bays | HDD Cage: 3.5″ HDD x1 & 2.5″ SSD X2 | |
| I/O Port | USB3.0 x 1, USB2.0 x 2, HD Audio | |
| Additional Feature | ||
| PSU | Not Include | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 160mm | |
| Maximum Graphics Card Length | 330mm | |
| Maximum PSU Length | 165mm | |
| Warranty | ||
| Warranty | No Warranty | |
