Key Features
- MPN: CA-1Q6-00M1WN-00
- Model: View 51 ARGB
- Tempered glass panel: 03 x 4 mm ( Front, Side, Up)
- Front Preinstalled Fans: 2 x white 200mm 5V ARGB fans
- Rear Preinstalled Fans: 1 x 120mm 5V ARGB fan
- Tt LCS Certified
Specification
| Case Type | ||
| Type | Full Tower | |
| Tempered Glass Panel | 4mm Tempered Glass x 3 (Right & Front & Top) |
|
| Motherboard Support | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13”(E-ATX) | |
| External Features | ||
| Color(s) | Black | |
| Material | SPCC | |
| Weight | 14.95 kg | |
| Dimensions | 550 x 315 x 525 mm | |
| Expansion Slots | 8 | |
| Radiator Support | Front: 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 280mm or 1 x 140mm Top: 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 280mm or 1 x 140mm Right: 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 280mm or 1 x 140mm Bottom: 1 x 360mm or 1 x 240mm or 1 x 120mm |
|
| Fan Support | Front: 2 x 200mm or 1 x 200mm 3 x 140mm or 2 x 140mm or 1 x 140mm 3 x 120mm or 2 x 120mm or 1 x 120mm Top: 2 x 200mm or 1 x 200mm 3 x 140mm or 2 x 140mm or 1 x 140mm 3 x 120mm or 2 x 120mm or 1 x 120mm Rear: 1 x 120mm , Right: 3 x 120mm or 2 x 120mm or 1 x 120mm 2 x 140mm or 1 x 140mm Bottom: 3 x 120mm or 2 x 120mm or 1 x 120mm |
|
| Pre- Installed Fans | Front (intake) : 2 x 200 x 200 x 30mm Addressable RGB fan (600rpm, 24dBA) Rear (exhaust) : 1 x 120 x 120 x 25mm Addressable RGB fan (1000rpm, 27.2 dBA) |
|
| Drive Bays | 2 x 2.5’’ (With HDD Bracket) 2 x 3.5’’ or 2.5’’ (With HDD Cage) |
|
| I/O Port | 1 x USB 3.1 (Gen 2) Type C, 2 x USB 2.0, 2 x USB 3.0, 1 x HD Audio, 1 x RGB Buttom |
|
| Additional Feature | ||
| Cooling System | Fan or Dual liquid cooler or custom cooler | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 175mm | |
| Maximum Graphics Card Length | 440mm | |
| Maximum PSU Length | 200mm | |
| Warranty | ||
| Warranty | No Warranty | |
