Key Features
- MPN: CA-1L2-00S1WN-00
- Model: Level 20 VT
- Type: Micro-ATX Casing
- Matarial: SPCC + Tempered glass
- Front Preinstalled Fans: 1x 200mm fan
- Tempered glass panel: 4mm (Left & Right & Front & Top)
Specification
| Case Type | ||
| Type | Micro ATX | |
| Front Panel | Tempered Glass | |
| Tempered Glass Panel | 4mm Tempered Glass x 4(Left & Right & Front & Top) | |
| Motherboard Support | 6.7” x 6.7” (Mini ITX) , 9.6” x 9.6” (Micro ATX) | |
| External Features | ||
| Color(s) | Exterior & Interior : Black | |
| Material | SPCC | |
| Weight | 8.66 kg / 19.09 lb | |
| Dimensions | 348 x 330 x 430 mm (13.7 x 13 x 16.9 inch) |
|
| Expansion Slots | 5 | |
| Radiator Support | Front: 1 x 240mm, 1 x 140mm, 1 x 180mm(200mm series) Top: 2 x 240mm, 1 x 280mm, 1 x 180mm(200mm series) Rear: 1 x 120mm |
|
| Fan Support | Front: 2 x 120mm, 2 x 140mm, 1 x 200mm Top: 4 x 120mm, 2 x 140mm Rear: 1 x 120mm, 1 x 140mm Bottom: 2 x 120mm |
|
| Pre- Installed Fans | one preinstalled 200mm front fan. | |
| Drive Bays | 3.5’’ or 2.5” x 3 , 2.5’’ x 3 | |
| I/O Port | USB 3.0 x 2,USB 2.0 x 2, HD Audio x 1 | |
| Additional Feature | ||
| Cooling System | Front (intake) : 200 x 200 x 30 mm fan (800rpm, 13dBA) | |
| PSU | Standard PS2 PSU (optional) | |
| Side Panel | 4mm Tempered Glass x 4(Left & Right & Front & Top) | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 185mm | |
| Maximum Graphics Card Length | 350mm | |
| Maximum PSU Length | 200mm (With Bottom Fan) | |
| Warranty | ||
| Warranty | No Warranty | |
