Key Features
- MPN: CA-1M7-00M1WN-00
- Model: Level 20 MT
- Type: ATX Casing
- Material: SPCC + Tempered glass
- Front Preinstalled Fans: 3x 120mm ARGB fan
- Rear Preinstalled Fan: 1x 120mm fan
Specification
| Case Type | ||
| Type | Mid Tower | |
| Front Panel | Tempered Glass | |
| Tempered Glass Panel | 4mm Tempered Glass x 2 (Left & Front) | |
| Motherboard Support | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) | |
| External Features | ||
| Color(s) | Black | |
| Material | SPCC | |
| Weight | 6.75 kg / 14.88 lb | |
| Dimensions | 455 x 204 x 471mm (17.9 x 8.0 x 18.54 inch) |
|
| Expansion Slots | 7 | |
| Radiator Support | Front: 1 x 360mm Rear: 1 x 120mm Right Side(In front of M/B Tray): 1 x 240mm |
|
| Fan Support | Front: 3 x 120mm Top: 2 x 120mm, 1 x 140mm Rear:1 x 120mm Right Side(In front of M/B Tray): 2 x 120mm Bottom(On the power cover): 2 x 120mm |
|
| Pre- Installed Fans | Front: 3 x 120mm ARGB Rear:1 x 120mm |
|
| Drive Bays | 1 x 2.5’’(HDD Bracket); 2 x 2.5” 2 x 3.5’’ or 2.5”(HDD Cage); 1 x 2.5”(HDD Bracket) |
|
| I/O Port | USB 3.0 x 2, HD Audio x 1, RGB Switch x 1 | |
| Additional Feature | ||
| Cooling System | Front (Intake): 120 x 120 x 25mm Addressable RGB fan (1000rpm, 27.2 dBA) x 3 Rear (exhaust): 120 x 120 x 25 mm fan (1000rpm, 26 dBA) x 1 |
|
| PSU | Standard PS2 PSU (optional) | |
| Side Panel | 4mm Tempered Glass x 2 (Left & Front) | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 170mm | |
| Maximum Graphics Card Length | 260mm(With radiator on the right side) 366mm(Without radiator on the right side) |
|
| Maximum PSU Length | 170mm | |
| Warranty | ||
| Warranty | No Warranty | |
