Key Features
- MPN: CA-1V1-00S1WN-00
- Model: Divider 200 TG
- Type: Micro-ATX Casing
- Material: SPCC + Tempered glass
- Preinstalled Fans: 1x 200mm fan front & 1x 120mm rear Fans
- Tempered glass panel: Three 3mm (Left, Front & Top)
Specification
| Case Type | ||
| Type | Micro-ATX Casing | |
| Tempered Glass Panel | 3mm Tempered Glass x 3 | |
| Motherboard Support | 6.7” x 6.7” (Mini ITX) , 9.6” x 9.6” (Micro ATX) | |
| External Features | ||
| Color(s) | Black | |
| Material | SPCC | |
| Weight | 9.01 kg / 19.9 lbs. | |
| Dimensions | 364.7 x 333.2 x 425.7 mm (14.4 x 13.1 x 16.8 inch) |
|
| Expansion Slots | 5 | |
| Radiator Support | Front: 1 x 240mm, 1 x 120mm, 1 x 280mm, 1 x 140mm Right: 1 x 240mm, 1 x 120mm, 1 x 280mm, 1 x 140mm Rear: 1 x 120mm |
|
| Fan Support | Front: 2 x 120mm, 1 x 120mm, 2 x 140mm, 1 x 140mm 1 x 200mm Right: 2 x 120mm, 1 x 120mm, 2 x 140mm, 1 x 140mm Rear: 1 x 120mm, 1 x 140mm, Bottom: 2 x 120mm, 1 x 120mm |
|
| Pre- Installed Fans | one preinstalled 200mm front fan one 120mm standard rear fan |
|
| Drive Bays | 3 x 3.5”, 3 x 2.5” or 6 x 2.5” |
|
| I/O Port | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 | |
| Additional Feature | ||
| Cooling System | Front (intake): 200 x 200 x 30 mm standard fan (800rpm, 13dBA) x 1 Rear(exhaust): 120 x 120 x 25 mm fan (1000rpm, 16 dBA) x 1 |
|
| PSU | Standard PS2 PSU (optional) | |
| Side Panel | empered Glass | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 185mm | |
| Maximum Graphics Card Length | 310mm (With 27mm radiator) 340mm (Without radiator) |
|
| Maximum PSU Length | 180mm (With Bottom Fan) 200mm (Without Bottom Fan) |
|
| Warranty | ||
| Warranty | 1-year Warranty | |
