Key Features
- MPN: TM8FF1001T0C129
- Model: Z540
- Capacity: 1TB
- Interface: PCIe Gen5x4 with NVMe
- Form Factor: M.2 2280
- Read/ Write Speed: Up to 12400 MB/s /11800 MB/s
Specification
| Key Features | ||
| Capacity | 1TB | |
| Form Factor | M.2 2280 | |
| Interface | PCIe Gen5x4 with NVMe | |
| Sequential R/W | Up to 12400 MB/s /11800 MB/s | |
| MTBF | 1,700,000 Hours | |
| TBW | 700 TBW | |
| Others | Humidity: RH 90% under 40°C (operational) Vibration: 80Hz~2,000Hz/20G Shock: 1,500G/0.5ms System Requirements: Windows 10 / 8.1 / 8 / 7, Linux 2.6.33 or later |
|
| Physical Specification | ||
| Dimension | 80.0(L) x 22.0(W) x 3.7(H) mm | |
| Weight | 13g | |
| Temperature | ||
| Operating Temperature | 0˚C ~ 70˚C | |
| Storage Temperature | -40˚C ~ 85˚C | |
| Shock resistance | 1,500G/0.5ms | |
| Warranty | ||
| Manufacturing Warranty | 5 Years Warranty | |
