Key Features
- MPN: TM8FPE001T0C611
- Model: T-CREATE CLASSIC
- Interface: PCIe Gen3x4 with NVMe 1.3
- Operation Temperature: 0˚C ~ 70˚C
- Vibration: 80Hz~2000Hz/20G
- Read/Write Speed: up to 2,100/1,700 MB/s
Specification
| Key Features | ||
| Capacity | 1TB | |
| Form Factor | M.2 | |
| Flash Type | Flash IC | |
| Interface | PCIe Gen3x4 with NVMe 1.3 | |
| Sequential R/W | Crystal Disk Mark: Read/Write: up to 2,100/1,700 MB/s IOPS: |
|
| MTBF | 1,500,000 hours | |
| Others | Humidity: RH 90% under 40°C (operational) Vibration: 80Hz~2,000Hz/20G |
|
| Physical Specification | ||
| Dimension | 80.0(L) x 22.0(W) x 3.7(H) mm (with Aluminum heat sink) | |
| Weight | 11g | |
| Temperature | ||
| Operating Temperature | 0˚C ~ 70˚C | |
| Storage Temperature | -40˚C ~ 85˚C | |
| Shock resistance | 1500G/0.5ms | |
| Warranty | ||
| Manufacturing Warranty | 5 years warranty | |
