Key Features
- MPN: 11295-03-20G
- Model: PULSE RX 5500 XT
- Boost Clock: Up to 1845 MHz
- Game Clock: Up to 1737 MHz
- Memory: 4GB/128-bit GDDR6. 14 Gbps Effective
- Stream Processors: 1408
Specification
| Video Memory Specifications | ||
| Type | GDDR6 | |
| Size | 4GB | |
| Resolution | HDMI: 4096×2160@60Hz DisplayPort1.4: 5120×2880@60Hz |
|
| Core Clock | Boost Clock: Up to 1845 MHz Game Clock: Up to 1737 MHz |
|
| Memory Clock | 14 Gbps Effective | |
| BUS Type | 128-bit | |
| Memory Interface | PCI-Express 4.0 | |
| Stream Processors | 1408 | |
| Others | RDNA Architecture 2nd Gen 7nm GPU Video Streaming up to 8K Radeon Rays Audio + True Audio Next Radeon FreeSync 2 HDR Radeon VR Ready Premium |
|
| Interface | ||
| Display Port | 3x DisplayPort 1.4 | |
| HDMI | 1x HDMI | |
| Power Specifications | ||
| Connectors | 1 x 8-pin Power Connector | |
| Recommended PSU | Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply). | |
| Consumption | 135W | |
| Display Option | ||
| Multi Display | Maximum 4 Outputs | |
| Application Programming Interfaces | ||
| DirectX | 12 | |
| OpenGL | 4.6 | |
| Physical Specifications | ||
| Dimensions | 233 x 121.8 x 39.6(mm) | |
| Others | 2 slot, ATX | |
| Warranty | ||
| Manufacturing Warranty | 02 years warranty | |
