Key Features
- MPN: 11296-01-20G
- Model: Sapphire Pulse Radeon RX 5600 XT
- GPU: Boost Clock: Up to 1750 MHz
- GPU: Game Clock: Up to 1615 MHz
- Memory: 6GB/192-bit GDDR6. 14 Gbps Effective
- Dual-X Cooling Technology
Specification
| Video Memory Specifications | ||
| Type | GDDR6 | |
| Size | 6GB | |
| Resolution | HDMI: 4096×2160@60Hz DisplayPort1.4: 5120×2880@60Hz Game Index: Extreme 1080P, 1440P Entry |
|
| Core Clock | Boost Clock: Up to 1750 MHz Game Clock: Up to 1615 MHz |
|
| Memory Clock | 14 Gbps Effective | |
| BUS Type | PCI Express 4.0 | |
| Memory Interface | 192 bit | |
| Stream Processors | 2304 | |
| Others | Sapphire Features: Power Design Free Flow TriXX Supported TriXX Boost Intelligent Fan Control IV Precision Fan Control Robust VRM Cooling Robust Memory Cooling Dual-X Cooling Technology Tough Metal Backplate PCB Layers Two-Ball Bearing Fan Quick Connect Fuse Protection Dual BIOS AMD Features: RDNA Architecture 2nd Gen 7nm GPU GDDR6 Memory Power Efficiency PCI Express 4.0 Support Video Streaming up to 8K Display Port 1.4 (HBR3) / DSC Radeon™ Software Radeon™ Boost Radeon™ Image Sharpening Radeon™ Anti-Lag AMD FidelityFx Async Compute Radeon™ Rays Audio + True Audio Next Radeon™ FreeSync™ 2 HDR Radeon™ VR Ready Premium |
|
| Interface | ||
| Display Port | 3x DisplayPort | |
| HDMI | 1x HDMI | |
| Power Specifications | ||
| Connectors | 1 x 8-pin | |
| Recommended PSU | Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply) | |
| Consumption | 160W | |
| Display Option | ||
| Multi Display | Yes ( Maximum 4 Outputs ) | |
| Application Programming Interfaces | ||
| DirectX | 12 | |
| OpenGL | 4.6 | |
| Physical Specifications | ||
| Dimensions | 254 x 135 x 46.5 mm | |
| Others | Sapphire Features: Power Design Free Flow TriXX Supported TriXX Boost Intelligent Fan Control Precision Fan Control Robust VRM Cooling Robust Memory Cooling Dual-X Cooling Technology Tough Metal Backplate PCB Layers Two-Ball Bearing Fan Quick Connect Fuse Protection Dual BIOS AMD Features: RDNA Architecture 2nd Gen 7nm GPU GDDR6 Memory Power Efficiency PCI Express 4.0 Support Video Streaming up to 8K Display Port 1.4 (HBR3) / DSC Radeon Software Radeon Boost Radeon Image Sharpening Radeon Anti-Lag AMD FidelityFx Async Compute Radeon Rays Audio + True Audio Next Radeon FreeSync 2 HDR |
|
| Warranty | ||
| Manufacturing Warranty | 2 Years Warranty | |
