Key Features
- MPN: 11348-01-20G
- Model: NITRO+ AMD Radeon RX 9070 XT
- Boost Clock: Up to 3060 MHz, Game Clock: Up to 2520 MHz
- Memory: 16GB/ 256 bit GDDR6, 20 Gbps Effective
- Stream Processors: 4096, AMD RDNA 4 Architecture
- Output Ports: 2x HDMI, 2x DisplayPort 2.1a
Specification
| Video Memory Specifications | ||
| Type | GDDR6 | |
| Size | 16GB | |
| Resolution | 7680×4320 | |
| Core Clock | Boost Clock: Up to 3060 MHz Game Clock: Up to 2520MHz |
|
| Memory Clock | 20 Gbps Effective | |
| BUS Type | 256 bit | |
| Memory Interface | PCI-Express 5.0 x16 | |
| Stream Processors | 4096 | |
| Others | Compute Units: 64 CUs (3rd Gen RT + 2nd Gen AI Accelerators) Infinity Cache: 64MB Ray Accelerators: 64 AI Accelerator: 128 Quick Connect MagniPlate STEALTH Hidden Power Cable 12V-2×6(H++) External Power Connector (3×8-pin power adapter is also included if your PC’s Power Supply Unit does not have 12V-2×6) Honeywell PTM7950 Thermal Interface Material (TIM) AeroCurve Fan Blade Free Flow FrameDefense Integrated Cooling Module Cold Rolled Steel Frame Tri-X Cooling Technology High TG Copper PCB Optimized Composite Heatpipes Metal Backplate ARGB Light Bar Fan Quick Connect Two-Ball Bearing Fans Premium 16-Phase Digital Power Design Fuse Protection Intelligent Fan Control Precision Fan Control TriXX Supported Performance vs. Efficiency Quicksets Glow! Fan Check TriXX Boost External RGB LED MB Synchronization L-Shape Support Bracket 3pin 5V ARGB Cable Magnetic Backplate 12V-2×6(H++) to PCI Express 3×8-pin power adapter AMD RDNA 4 Architecture 64 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators) AMD HYPR-RX with AFMF 2 AMD FidelityFX Super Resolution 4 with AI Upscaling DisplayPort 2.1a AMD Radiance Display Engine AMD Fluid Motion Frames 2 technology AMD Radeon Anti-Lag 2 technology AV1 Encode/Decode AMD FidelityFX technologies Microsoft DirectX 12 Ultimate AMD Noise Suppression AMD Freesync technology AMD smart technologies AMD Software: Adrenalin Edition application Tri-X Cooling AeroCurve Fan Blade Free Flow Integrated Cooling Module High TG Copper PCB Optimized Composite Heatpipes Two-Ball Bearing |
|
| Interface | ||
| Display Port | 2 x DisplayPort 2.1a | |
| HDMI | 2 x HDMI | |
| Power Specifications | ||
| Connectors | 2 x 8-pin Power Connector | |
| Recommended PSU | Minimum 750 Watt Power Supply | |
| Consumption | 330W Typical Board Power | |
| Display Option | ||
| Multi Display | 4 | |
| Application Programming Interfaces | ||
| DirectX | Microsoft DirectX 12 Ultimate | |
| Physical Specifications | ||
| Dimensions | 330.8(L)X 128.5(W)X 65.68 (H)mm | |
| Others | 3.2 slot, ATX | |
| Warranty | ||
| Manufacturing Warranty | 2 years | |
