Key Features
- MPN: CM-H71EW-02
- Model: H7 Elite V2 2023
- Motherboard Support: Mini-ITX, Micro-ATX, ATX
- Enclosure Type: Mid-Tower
- 4 x F140 RGB Core Fan
- NZXT RGB Connector: 3 (Support up to 120 LEDs)
Specification
| Case Type | ||
| Type | Mid-Tower | |
| Front Panel | Mesh | |
| Tempered Glass Panel | Yes | |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX | |
| External Features | ||
| Color(s) | White | |
| Material | SGCC Steel, Dark Tinted Tempered Glass (Black only) | |
| Weight | 11.36 kg | |
| Dimensions | Height: 505mm (With Feet) Width: 230mm Depth: 480mm |
|
| Front Ports | 2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2×2 Type-C (20 Gbps) 1 x Headset Audio Jack |
|
| Expansion Slots | Standard: 7 | |
| Radiator Support | Front: Up to 360mm with Push/Pull Top: Up to 360mm Rear: Up to 140mm |
|
| Fan Support | Front: 3 x 120mm / 3 x 140mm Top: 3 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm Filters: All Air Intakes |
|
| Pre- Installed Fans | Front: 3 x F140 RGB Core Fan Rear: 1 x F140Q Airflow Fan (Case Version) |
|
| Drive Bays | 2.5”: 4+2 3.5”: 2 |
|
| I/O Port | Fan Connector: 4-pin PWM | |
| Clearance Space | ||
| Maximum CPU Cooler Height | Up to 185mm | |
| Maximum Graphics Card Length | Up to 400mm | |
| Warranty | ||
| Warranty | No Warranty | |
