Key Features
- MPN: CC-H61FW-R1
- Model: H6 Flow 2023
- Motherboard Support: ATX, Micro-ATX, Mini-ITX
- Enclosure Type: Mid-Tower
- 3x F120 RGB Core case version included
- SGCC Steel, Ultra-Clear Tempered Glass
Specification
| Case Type | ||
| Type | Mid-Tower | |
| Front Panel | Glass, Mesh | |
| Tempered Glass Panel | Yes | |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX | |
| External Features | ||
| Color(s) | White | |
| Material | SGCC Steel, Ultra-Clear Tempered Glass, Dark Tinted Tempered Glas | |
| Weight | 9.4 kg | |
| Dimensions | Height (with feet): 435 mm / 17.13 in Width: 287 mm / 11.3 in Depth: 415 mm / 16.34 in |
|
| Front Ports | 2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2×2 Type-C (20 Gbps) 1 x Headset Audio Jack |
|
| Expansion Slots | Standard: 7 | |
| Radiator Support | Top: Up to 360 mm Rear: Up to 120 mm |
|
| Fan Support | Front-Right: 3 x 120 mm (3 x F120 RGB Core case version included) Top: 3 x 120 mm / 2 x 140 mm Bottom: 2 x 140 mm Rear: 1 x 120 mm Speed: |
|
| Pre- Installed Fans | 3 x 120 mm (3 x F120 RGB Core case version included) | |
| Drive Bays | 2.5″: 2 3.5″: 1 |
|
| Others | High-Performance Mesh | |
| Additional Feature | ||
| PSU | Not Included | |
| Clearance Space | ||
| Maximum CPU Cooler Height | Up to 163 mm / 6.42 in | |
| Maximum Graphics Card Length | Up to 365 mm / 14.37 in | |
| Maximum PSU Length | Up to 200 mm / 7.87 in | |
| Warranty | ||
| Warranty | No Warranty | |
