Key Features
- MPN: CC-H51FW-R1
- Model: H5 Flow
- Motherboard Support: Mini-ITX, Micro-ATX, ATX
- Enclosure Type: Mid-Tower
- Pre installed Fan: 2x F140 RGB, 2x F120Q Airflow Fan
- Steel Frame & Tempered Glass Window
Specification
| Case Type | ||
| Type | Mid-Tower | |
| Front Panel | Mesh | |
| Tempered Glass Panel | Yes | |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX | |
| External Features | ||
| Color(s) | White | |
| Weight | 7.36 kg | |
| Dimensions | Height (With Feet): 464mm Height (Without Feet): 448mm Width: 227mm Depth: 446mm |
|
| Front Ports | 1 x USB 3.2 Gen 1 Type-A: 1 x USB 3.2 Gen 2 Type-C 1 x Headset Audio Jack |
|
| Expansion Slots | Standard: 7 | |
| Radiator Support | Front: Up to 280mm Top: Up to 240mm Rear: Up to 120mm |
|
| Fan Support | Front: 2 x 120mm / 2 x 140mm Top: 2 x 120mm Rear: 1 x F Series Quiet 120mm (Case Version) included Bottom: 1 x F Series Quiet 120mm (Case Version) included |
|
| Pre- Installed Fans | Front: 1 x 120 mm Rear: 1 x 120 mm |
|
| Drive Bays | 2.5″: 1+1 3.5″: 1 |
|
| Additional Feature | ||
| PSU | Not Included | |
| Clearance Space | ||
| Maximum CPU Cooler Height | Up to 165mm | |
| Maximum Graphics Card Length | Up to 365mm | |
| Maximum PSU Length | Up to 185mm | |
| Warranty | ||
| Warranty | No Warranty | |
