Key Features
- Model: SPATIUM M461
- Capacity: 2TB
- Interface: PCIe Gen4x4, NVMe 1.4
- Form Factor: M.2 2280
- Read: 5000MB/s, Write: 4200MB/s
Specification
| Key Features | ||
| Capacity | 2TB | |
| Form Factor | M.2 2280 | |
| Flash Type | 3D NAND | |
| Interface | PCIe Gen4x4, NVMe 1.4 | |
| Sequential R/W | 5000/4200MB/s | |
| MTBF | Up to 1,500,000 Hours | |
| TBW | 450 | |
| Others | PHISON E21T Controller TRIM (Performance Optimization, OS Support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low-Density Parity Check) ECC Algorithm End-to-End Data Path Protection APST (Autonomous Power State Transition) Pyrite (Encryption, Data Security) |
|
| Physical Specification | ||
| Dimension | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) | |
| Temperature | ||
| Operating Temperature | 0°C – 70°C | |
| Storage Temperature | -40°C – 85°C | |
| Warranty | ||
| Manufacturing Warranty | 5 Years | |
