Key Features
- Model: MAG PANO 100R PZ
- Case Type: Mid Tower
- Motherboard Support: ATX / Micro-ATX / Mini-ITX
- Supports up to 10 x 120 mm system fans
- Pre-installed Fans: 4 x 120mm ARGB Reverse-blade
Specification
| Case Type | ||
| Type | Mid Tower | |
| Tempered Glass Panel | 270-degree panoramic tempered glass | |
| Motherboard Support | Regular: ATX / Micro-ATX / Mini-ITX Back-connect: ATX / Micro-ATX |
|
| External Features | ||
| Color(s) | Black | |
| Dimensions | 518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches |
|
| Expansion Slots | 8 | |
| Radiator Support | Top: 120 / 240 / 360 mm Front: NA Rear: 120 mm Side: 120 / 240 / 360 mm Bottom: 120 / 240 / 360 mm |
|
| Fan Support | Top: 3 x 120 mm / 3 x 140 mm Front: NA Rear: 1 x 120 mm Side: 3 x 120 mm / 2 x 140 mm Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm |
|
| Pre- Installed Fans | Side: 3 x ARGB Reverse-blade Rear: 1 x ARGB |
|
| Drive Bays | 1 x 2.5” 1 x 2.5”/3.5” combo (up to 2 x 2.5” or 1 x 2.5”+ 1 x 3.5”) |
|
| I/O Port | 1 x USB 20Gbps Type-C 2 x USB 5Gbps Type-A 1 x Audio-Out / Mic-in 1 x LED Switch Button 1 x Power Button |
|
| Clearance Space | ||
| Maximum CPU Cooler Height | 166 mm / 6.54 inches | |
| Maximum Graphics Card Length | 380 mm / 14.96 inches | |
| Maximum PSU Length | 200 mm / 7.87 inches | |
| Warranty | ||
| Warranty | No Warranty | |
