Key Features
- MPN: G5090-32SLS
- Model: GeForce RTX 5090 32G SUPRIM LIQUID SOC
- Video Memory: 32GB GDDR7, PCI Express 5.0 x16
- Core Clocks: Gaming Mode: 2580 MHz, Silent Mode: 2527 MHz
- CUDA Cores: 21760 Units, Memory Speed: 28 Gbps
- Display Outputs: 3 x DisplayPort 2.1b, 1 x HDMI
Specification
| Video Memory Specifications | ||
| Type | GDDR7 | |
| Size | 32GB | |
| Resolution | up to 15360×8460 @ 60Hz | |
| Core Clock | Gaming Mode: Extreme Performance: 2580 MHz (MSI Center) Boost: 2565 MHz Silent Mode: Extreme Performance: 2527 MHz (MSI Center) Boost: 2512 MHz |
|
| BUS Type | 512-bit | |
| Memory Interface | 28 Gbps | |
| CUDA Cores | 21760 Units | |
| Interface | ||
| Display Port | DisplayPort x 3 (2.1b) | |
| HDMI | HDMI x 1 (As specified in HDMI 2.1b: up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) |
|
| HDCP | Yes | |
| Power Specifications | ||
| Connectors | 16-pin x 1 | |
| Recommended PSU | 1000 W | |
| Display Option | ||
| Multi Display | Quad Display | |
| Application Programming Interfaces | ||
| DirectX | 12 Ultimate | |
| OpenGL | 4.6 | |
| Physical Specifications | ||
| Others | Powered by the NVIDIA Blackwell architecture and DLSS 4 Superior Hybrid Cooling System Advanced Performance Pump Patented Water Block Design Micro-fin Copper Base 360 mm Aluminum Radiator Durable Tubing with Scratch-proof Cover Metal Backplate Dual BIOS |
|
| Warranty | ||
| Manufacturing Warranty | 3 years | |
