Key Features
- Model: W4033-LF
- Capacity: 40KVA
- Load Capacity: 125% load keep 10min,150% load keep 30s
- Input Voltage: 380±25% V
- Output Voltage: 380/400/415±1％ V
Specification
| Main Feature | ||
| Capacity | 40KVA | |
| Display Type | General LCD | |
| Load Capacity | Overload: 125% load keep 10min,150% load keep 30s | |
| Input Voltage | 380±25% | |
| Output Voltage | 380/400/415±1％ | |
| Frequency (Battery Mode) | 45～66 Automatically select synchronization range according to grid frequency | |
| Noise Level | <65(within 1 meter) | |
| Alarm | Battery low-voltage, mains abnormal, overload, UPS fault, over temperature protection | |
| Input Features | ||
| Frequency | 45～66 Automatically select synchronization range according to grid frequency | |
| Voltage Range | ||
| Output Features | ||
| Backup Time | Depends on customer configuration | |
| Type of Wave | Sine Wave,THD<3% | |
| Transfer Time | 00 | |
| Manufacture Warranty | ||
| Warranty | One Year Warranty (UPS and Battery). | |
