Key Features
- Model: MGO-BG6033-LF
- IGBT inverter and output isolation transformer
- Online double conversion
- Wide input voltage range
- RS232/RS485 communication port
Specification
| Main Feature | ||
| Capacity | 60KVA | |
| Input Voltage | 380±25% | |
| Output Voltage | 380/400/415±1％ | |
| Rectifier Type | IGBT | |
| Alarm | Battery low-voltage, mains abnormal, overload, UPS fault, over-temperature protection | |
| Input Features | ||
| Frequency | 45～66 (automatically selects synchronization range according to grid frequency) | |
| Voltage Range | 380±25% | |
| Output Features | ||
| Backup Time | Battery supply life can be configured freely | |
| Voltage Range | 380/400/415±1％ (Isolation transformer output) | |
| Power Factor | 0.8 | |
| Type of Wave | Sine Wave, THD<3% | |
| Manufacture Warranty | ||
| Warranty | 01 Year Warranty | |
