Key Features
- Model: B2033-LF
- Capacity: 20KVA
- Voltage Range: 380±25%
- Power Factor: 0.8/0.9
- IGBT inverter and output isolation transformer
Specification
| Main Feature | ||
| Capacity | 20 KVA | |
| Display Type | General LCD | |
| Load Capacity | Overload: 125% load keep 10min,150% load keep 30s | |
| Input Voltage | 380±25% | |
| Frequency (Battery Mode) | 45～66 Automatically select synchronization range according to grid frequency | |
| Noise Level | <60(within 1 meter) | |
| Alarm | Battery low-voltage, mains abnormal, overload, UPS fault, over temperature protection | |
| Input Features | ||
| Frequency | 45～66 Automatically select synchronization range according to grid frequency | |
| Voltage Range | 380±25% | |
| Output Features | ||
| Backup Time | depends on customer configuration | |
| Voltage Range | 380/400/415±1％, Isolation transformer output | |
| Power Factor | 0.8/0.9 | |
| Type of Wave | Sine Wave,THD<3% | |
| Manufacture Warranty | ||
| Warranty | 1 Year | |
