Key Features
- Model: NM610 PRO
- Interface: PCIe Gen3x4
- Form Factor M.2 2280
- Sequential Read: Up to 3300MB/s
- Sequential Write: Up to 2600MB/s
Specification
| Key Features | ||
| Capacity | 1TB | |
| Form Factor | M.2 2280 | |
| Interface | PCIe Gen3x4 | |
| Sequential R/W | read up to 3300MB/s write up to 2600MB/s |
|
| MTBF | 1,500,000 Hours | |
| TBW | 240TBW | |
| Physical Specification | ||
| Dimension | 80 mm x 22 mm x 2.45 mm / 3.15” x 0.87” x 0.10” | |
| Weight | 9g | |
| Temperature | ||
| Operating Temperature | 0° C to 70° C (32°F to 158°F) | |
| Storage Temperature | -40° C to 85° C (-40°F to 185°F) | |
| Shock resistance | 1500G, duration 0.5ms, Half Sine Wave | |
| Vibration Resistance | 10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z) | |
| Warranty | ||
| Manufacturing Warranty | 03 years warranty | |
