Key Features
- Model: DS-UPS650
- Built-in AVR
- Surge protection
- 650 VA / 360 W
- Battery 12 V/7 Ah ×1
Specification
| Main Feature | ||
| Capacity | 600 VA | |
| Load Capacity | 360 W | |
| Input Voltage | 140 VAC to 290 VAC; 85 VAC to 150 VAC | |
| Output Voltage | 210 VAC to 235 VAC;110 VAC to 125 VAC | |
| Frequency (Battery Mode) | 50/60 Hz ± 0.5 Hz self-adaptive | |
| Battery | 12 V/7 Ah ×1 | |
| Alarm | Charging Mode (DC mode): Sounding every 10 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding |
|
| Others | Surge protection, Overload protection, Discharge protection, Overcharge protection | |
| Input Features | ||
| Frequency | 50/60 Hz self-adaptive | |
| Voltage Range | 140 VAC to 290 VAC | |
| Output Features | ||
| Type of Wave | PWM | |
| Transfer Time | ≤ 10 ms | |
| Manufacture Warranty | ||
| Warranty | 1 year | |
