Key Features
- Model: UD1300GM PG5
- Power Output Capacity: 1300W, Compact design
- 80 PLUS Gold Certified, Main Japanese Capacitors
- Fan Type: 140mm Double Ball Bearing Fan
- OVP/OPP/SCP/UVP/OCP/OTP
Specification
| Key Features | ||
| Efficiency (Approx.) | 90% at typical load | |
| Certification | 80 PLUS Gold | |
| Fan Size | 140mm double ball bearing fan | |
| Others | Support PCIe Gen 5.0 graphics card Support Intel ATX 3.0 standard Fully modular design |
|
| Input | ||
| Voltage | 100-240 Vac (full range) | |
| Frequency Range | 60-50 Hz | |
| Current | 15-6.5A | |
| Output | ||
| Modular Type | Full Modular | |
| Total Power | 1300W | |
| Connector | ||
| Main Power | ATX/MB 20+4 Pin x 1 : 610mm*1 | |
| CPU | CPU/EPS 4+4 Pin x 2 : 650mm*2 | |
| PCI-E | PCIe 6+2 Pin x 8 : 650mm+150mm*3, 650mm*2 | |
| SATA | SATA x 12 : 650mm+150mm+150mm+150mm*3 | |
| Floppy | 4 Pin Peripheral x 6+4-Pin floppy x 2 : 600mm+150mm+150mm+150mm*2 | |
| Warranty Information | ||
| Manufacturing Warranty | 10-Years | |
