Key Features
- Model: HELIOS M1-750B
- Total Output Power: 750 Watt
- Power Supply Type: ATX12V v2.4
- Certification: 80 PLUS Bronze Certified
- Cooling System: 120mm Hydraulic Bearing Fan
Specification
| Key Features | ||
| Efficiency (Approx.) | 85% Efficiency | |
| Certification | 80 PLUS Bronze | |
| Fan Size | 120mm hydraulic bearing fan | |
| Others | Type: ATX12V v2.4 Power Factor Correction: APFC with PF value of 0.99 Protection: OVP / UVP / OPP / OCP / SCP |
|
| Input | ||
| Voltage | 100-240V | |
| Frequency Range | 47-63Hz | |
| Current | 5.5-11A | |
| Output | ||
| Modular Type | Non Modular | |
| Total Power | 750W | |
| AC Input | 100-240V / 5.5-11A / 47-63Hz | |
| DC Output | +3.3V / +5V / +12V / -12V / +5Vsb | |
| Connector | ||
| Main Power | 1 (20+4 Pin) | |
| CPU | 1 (4+4 Pin) | |
| PCI-E | 4 (6+2 Pin) | |
| SATA | 5 (5 Pin) | |
| Molex | 3 (4 Pin) | |
| Warranty Information | ||
| Manufacturing Warranty | 6 Years | |
