Key Features
- MPN: R-LS520-BKAMNT-G-1 / R-LS520-BKAMMMD-G-1
- Model: LS520
- Radiator Dimensions: 402×120×27 mm
- Fan Dimensions: 120×120×25 mm
- Fan Connector: 4-pin PWM
- Bearing Type: Fluid Dynamic Bearing
Specification
| Key Features | ||
| Type | Fluid Dynamic Bearing Liquid CPU Cooler | |
| Fan Speed | 500~2250 RPM±10% | |
| Fan Airflow | 85.85 CFM | |
| Noise | Pump Noise 19 dB(A) Fan Noise ≤32.9 dB(A) |
|
| Air Pressure | 3.27 mmAq | |
| Connector | Pump Connector: 3-pin Fan Connector: 4-pin PWM |
|
| Material | Radiator Material: Aluminum | |
| Others | Tube length: 410 mm Pump Speed: 3100 RPM±10% |
|
| Physical Specification | ||
| Dimension | Radiator Dimensions: 282×120×27 mm Pump Dimensions: 86×74×57 mm Fan Dimensions: 120×120×25 mm |
|
| Weight | 1305 g | |
| Supported Sockets | ||
| Intel | LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 | |
| AMD | sTRX4/sTR4/AM5/AM4 | |
| Warranty Information | ||
| Warranty | 05-year warranty | |
