Key Features
- MPN: DP-230EU-DN550
- Model: DN550
- Type: ATX12V V2.4
- Output Capacity: 550W
- Certifications: 80 PLUS
- Fan Size: 120mm, Fan Bearing: Hypro Bearing
Specification
| Key Features | ||
| Efficiency (Approx.) | 85% Under Typical Load | |
| Certification | 80 PLUS Standard | |
| Fan Size | 120mm | |
| Input | ||
| Voltage | 200-240V | |
| Frequency Range | 47~63Hz | |
| Current | 4A | |
| Output | ||
| Total Power | 100-500ms | |
| Connector | ||
| Main Power | Main Power Connector (20+4)Pin x 1 | |
| CPU | CPU(4+4)Pin x 1 | |
| PCI-E | PCI-E(6+2)Pin x 1 | |
| SATA | SATAx3 +4pin Peripheralx1 SATAx2 +4pin Peripheralx2 |
|
| Warranty Information | ||
| Manufacturing Warranty | 05-Years warranty | |
