Key Features
- MPN: DP-F12-AR-CF120P-3P
- Model: CF120 PLUS
- Support A-RGB motherboard synchronization
- Balanced cooling performance & noise level
- Ring + blade A-RGB LED lighting
- Wire controller included
Specification
| Key Features | ||
| Fan Speed | 500~1800 RPM±10% | |
| Air Flow | 52.5 CFM | |
| Noise (dBA) | ≤28.8 dB(A) | |
| Input Current | FAN Rated Current 0.18A LED Rated Current 0.63A |
|
| Operating Voltage/Power Range | FAN Rated Voltage 12VDC LED Rated Voltage 5VDC LED Rated Power 3.15W |
|
| Physical Specification | ||
| Color | Black color with Addressable RGB LED | |
| Size | Fan Dimension: 120×120×26.5mm | |
| Weight | 569g | |
| Connector | Fan Connector 4-Pin PWM LED Connector 3-pin（+5V-D-G） |
|
| Others | ||
| Others | LED Type: Addressable RGB LED Fan Air Pressure 2.08 mmAq Fan Noise Level ≤28.8 dB(A) FAN Power Consumption 2.16W |
|
| Warranty Information | ||
| Manufacturing Warranty | 01 year warranty | |
