Key Features
- Model: UNIFACE MINI RGB
- Case Form Factor: Mini Tower
- Motherboard Support: Mini ITX / Micro ATX
- Pre Installed Fans: 3 x ARGB Fan
- Max GPU Length: 340mm, CPU Cooler Height: 160mm
Specification
| Case Type | ||
| Type | Mini Tower | |
| Front Panel | Mesh | |
| Tempered Glass Panel | Side Panel | |
| Motherboard Support | Mini ITX / Micro ATX | |
| External Features | ||
| Color(s) | White | |
| Dimensions | 210 x 422 x 390 (mm) 8.3 x 16.6 x 15.4 (in) |
|
| Front Ports | USB 3.0 x 2, USB 2.0 x 1, Mic x 1 / Audio x 1, RGB Button |
|
| Expansion Slots | 4 | |
| Fan Support | Front: 120mm x 3 / 140mm x 2 Top: 120mm x 2 / 140mm x 2 Rear: 120mm x 1 Maximun Number of Fans 6 |
|
| Pre- Installed Fans | Front: 140mm ARGB fan x 2 Rear: 120mm ARGB fan x 1 Speed: 140mm ARGB fan: 1000 ± 10% RPM 120mm ARGB fan: 1200 ± 10% RPM Connector: 5V 3 Pin (ARGB) / 3 Pin (Fan) |
|
| Drive Bays | 3.5″ Drive Bay: 2 2.5″ Drive Bay: 2+2 (converted from 3.5″ drive bays) |
|
| I/O Port | USB 3.0 x 2, USB 2.0 x 1, Mic x 1 / Audio x 1, RGB Button | |
| Others | RGB Hub Sync with M/B | |
| Additional Feature | ||
| Side Panel | Tempered Glass | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 160 (mm) / 6.3 (in) | |
| Maximum Graphics Card Length | 340 (mm) / 13.4 (in) | |
| Maximum PSU Length | 160 (mm) / 6.3 (in) | |
| Warranty | ||
| Warranty | No Warranty | |
