Key Features
- Model: BATTLE-AX H610M-E WIFI V20
- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 2x DDR4, Max 64GB 3200(OC)
- Graphics Output: 1×VGA, 1x HDMI
- Features: RTL8111H Gbit network card, WiFi 5
Specification
| Basic Information | ||
| Supported CPU | Support the 14th/13th and 12th generation Intel adapting to the LGA 1700 slot of the motherboard Core TM, Pentium And Cylon processor | |
| Chipset | Intel H610 | |
| BIOS | 128M UEFI, supporting multiple languages | |
| Form Factor | M-ATX 245mm x 245mm |
|
| Audio | 5.1 sound card | |
| Expansion Slots | ||
| PCI | 1xPCIe 4.0 x16 slot 1xPCIe 3.0 x1 slot |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 2 | |
| Supported Memory | – DDR4-3200/2933/2666/2400MHz memory – support dual-channel memory technology |
|
| Maximum Memory | support up to 64 GB of memory (a single slot can support up to 32 GB of memory) | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI 2.0 interface, Up to 4K 60Hz resolution – 1×VGA interface |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| VGA (s) | – 1×VGA interface | |
| LAN Port (s) | RTL8111H Gigabit network card | |
| Wireless Communication module | RTL8821CE/AC3165 WiFi 5 Wireless network, Bluetooth 4.2 | |
| Supported Storage | A total of 1 M.2 slot and 4 SATA 6Gb/s hard disk interfaces are supported – M2_ 1 slot: supports 2242/2280 specification M.2 SSD (PCIe 3.0 x4, PCH channel) |
|
| Internal I/O Ports | Rear I/O: – 1×PS/2 interface – 4×USB 2.0 interfaces – 2×USB 3.2 Gen 1 Type-A interfaces – 1×HDMI 2.0 interface, Up to 4K 60Hz resolution – 1×VGA interface – 1×Gigabit network interface – 3×Audio interfaces (audio input/audio output/microphone) On board: – 1×CPU fan pin – 2×System fan pins – 1×water cooling pump pin – 1×USB 2.0 pin can expand 2 USB 2.0 Type-A interfaces – 1×USB 3.2 Gen 1 pin can expand 2 USB 3.2 Gen 1 Type-A interfaces – 1×Front audio pin – 1×Front panel pin – 1×Speaker pin – 1×COM port pin – 1×ME write protection jumper – 1×Clear CMOS jumper – 1×BIOS burner pin – 1×POST Card pin – 1×Wake-up control jumper |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
