Key Features
- Model: 2B6K
- Capacity: 6kVA
- Input Voltage: 110 V -220 V, Output Voltage: 220V
- Topology: Online
- Short Circuit, Overload and Overcharge Protection
Specification
| Main Feature | ||
| Capacity | 6KVA | |
| Display Type | LCD | |
| Input Voltage | 110VAC±20%/220VAC±25% | |
| Output Voltage | 110V±1%/220V±1% | |
| Noise Level | <58dB at 1 meter | |
| Battery | Battery Backup: 15 to 20 Min (Depends on Load) | |
| Alarm | AC fault, Battery low voltage, UPS over load, UPS fault | |
| Others | Protection: Overload, Battery, Short circuit, Over temperature, EMI filter Interface: RS232 Temperature: 0℃~40℃ Humidity: 20~90% No condensing |
|
| Input Features | ||
| Frequency | 60Hz±5%/50Hz±5% | |
| Voltage Range | 110VAC±20%/220VAC±25% | |
| Output Features | ||
| Voltage Range | 110V±1%/220V±1% | |
| Power Factor | 0.8-1 LAG | |
| Type of Wave | Sine wave | |
| Transfer Time | AC fault: 0ms UPS fault: <2ms |
|
| Physical Specification | ||
| Dimension | 585x230x580mm | |
| Weight | 126 kg | |
| Manufacture Warranty | ||
| Warranty | 1 Year (Box Mandatory While Claiming) | |
