Key Features
- Model: NX420
- Mainboard Support: ATX, M-ATX, ITX
- Form Factor: Mid Tower
- Tempered Glass Side Panel
- Materials: SPCC+Plastic
Specification
| Case Type | ||
| Type | Mid Tower | |
| Front Panel | ARGB lighting effect | |
| Tempered Glass Panel | Yes | |
| Motherboard Support | ATX, M-ATX, ITX | |
| External Features | ||
| Color(s) | Black | |
| Weight | Net Weight : 5kg Gross Weight : 5.8kg |
|
| Dimensions | 416 X 221 X 463 mm (DxWxH) | |
| Expansion Slots | 7 | |
| Radiator Support | Front: 120 / 140 / 240 / 280 / 360 mm Top: 120 / 240 mm Rear: 120 mm |
|
| Fan Support | Front: 3 x 120 / 2 x140 mm Top: 2 x 120 / 2 x140 mm Rear: 1 x 120 / 1 x 140 mm |
|
| Pre- Installed Fans | 1 x 120 mm regular fan in rear | |
| Drive Bays | 3.5″ /2.5″: 2/1 2.5″: 4 |
|
| I/O Port | Power, Reset, LED Control button, MIC/HD-AUDIO, USB 2.0 x2, USB 3.0 x 1 |
|
| Additional Feature | ||
| PSU | 185 mm (with HDD) 355 mm (without HDD) |
|
| Side Panel | Tempered Glass Side Panel | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 175 mm | |
| Maximum Graphics Card Length | 330 mm | |
| Warranty | ||
| Warranty | No Warranty | |
