Key Features
- Model: R2
- Motherboard Support: M-ATX
- Expansion Slots: 4
- Left Side Panel: Tempered Glass
- I/O Panel: USB3.0 x1, USB2.0 x2, HD Audio
Specification
| Case Type | ||
| Tempered Glass Panel | LEFT SIDE | |
| Motherboard Support | M-ATX | |
| External Features | ||
| Color(s) | Black | |
| Material | SPCC 0.45mm | |
| Dimensions | 345*195*400mm | |
| Expansion Slots | 4 | |
| Fan Support | Front: 3*120mm Back: 1*120mm Bottom: 2*120mm |
|
| Drive Bays | 3.5″ HDD: 1 + 2.5″ SSD: 2 3.5″ HDD: 2 + 2.5″ SSD: 1 |
|
| I/O Port | USB3.0 x1, USB2.0 x2, HD Audio | |
| Additional Feature | ||
| PSU | Not Include | |
| Clearance Space | ||
| Maximum CPU Cooler Height | 170mm | |
| Maximum Graphics Card Length | 310mm | |
| Warranty | ||
| Warranty | No Warranty | |
